Digital Oil Pressure Gauge RPM / Speed / Turbo / AFR / Oil Temp / Water Temp

Product Description

RPM / Speed / Turbo / AFR / Oil Temp / Water Temp / Oil Pressure Combination Race Gauges

The DPU has 11 sockets, as shown below. Sockets 1 to 11 are connected to the devices with corresponding numbers:

1. spare socket

       2. spare socket

3. power

4. Boost sensor

5. Oil Pressure sensor

6. Air Fuel Ratio sensor

7. Oil Temp sensor

8. Water Temp sensor

9. Exhaust Gas Temp sensor

10. RPM (green wire) and Speed meter (red wire)

11. spare socket

IMPORTANT: There are two types of alarms: 1. Speed alarm. 2. RPM alarm. When alarm is selected "ON", when any of the following two factors is satisfied, the alarm will be triggered:

a) Exceeding the speed limit.

b) Exceeding the red LED light's RPM value.
